WELDLESS HEAVY DUTY MASTER LINK GRADE 80 4-1/2" (HDGPML0250)

The HDGPML0250 Green Pin® Heavy Duty Master Link, available for Canadian distribution through Vancouver Rigging Supply Ltd., offers a 250 t working load limit. This grade 8 master link, forged as a single piece without welds, meets strict safety and performance requirements for demanding industrial applications.

Key specifications include:

• Diameter: 4 1/2" (114.3 mm)
• Inside length: 23 5/8" (600.1 mm)
• Inside width: 15 3/4" (400.1 mm)
• Net weight: 379 LBS (171.9 kg)

The silver-painted master link features a green mark indicating a maximum lifting angle of 120 degrees, aiding in operation safety. Its smooth surface minimizes wear on associated components like slings and shackles.

This product undergoes multiple non-destructive tests to ensure structural integrity. With a consistent Charpy-V Value of at least 42 Joule throughout, it complies with offshore certification requirements.

The Green Pin® Heavy Duty Master Link serves various industries, including:

• Offshore oil and gas
• Marine and shipyard operations
• Construction and infrastructure projects
• Mining and quarrying

To inquire about the HDGPML0250 for your Canadian rigging needs, click the 'Add to Quote' button on this page.
