WELDLESS HEAVY DUTY MASTER LINK GRADE 80 3-1/2" (HDGPML0131)

The Green Pin® Heavy Duty Master Link (HDGPML0131) from Vancouver Rigging Supply Ltd. is a grade 8 component engineered for substantial load-bearing applications. This 3 1/2" (89 mm) diameter master link boasts a working load limit of 131 t, making it suitable for extensive industrial operations.

Key specifications include:

• Inside length: 18 1/8" (460 mm)
• Inside width: 11 13/16" (300 mm)
• Net weight: 170 LBS (77 kg)

Manufactured through a one-piece forging process, this master link eliminates welding, adhering to rigorous safety standards. The silver finish features a green mark indicating a maximum 120-degree lifting angle, assisting operators in maintaining proper usage.

Industries benefiting from this product include:

• Offshore oil and gas
• Marine construction
• Heavy machinery transport
• Mining operations

The Green Pin® Heavy Duty Master Link undergoes non-destructive testing and maintains a Charpy-V Value of 42 Joule throughout, meeting offshore certification requirements. Its polished surface minimizes wear on associated components like slings and shackles.

Canadian companies can request a quote for this product by clicking the 'Add to Quote' button on this page.
