PRODUCT CODE: G-6314 | PART NUMBER: SSGPHO1206

GREEN PIN EYE HOOK TURNBUCKLE 1/2” X 6” (SSGPHO1206)

The Green Pin® Eye Hook Turnbuckle 1/2" X 6" (SSGPHO1206) is a precision-engineered rigging component designed for load adjustment in various industrial applications. This turnbuckle, part of the G-6314 series, combines the functionality of an eye and a hook in a single unit.

Key Specifications:

  • Working Load Limit: 1 t
  • Take-up: 6" (152 mm)
  • Thread Diameter: 1/2" (12.7 mm)
  • Closed Length: 2 9/32" (57.9 mm)
  • Open Length: 17 9/16" (446 mm)
  • Hook Thickness: 7/8" (22.2 mm)
  • Hook Opening: 5/8" (15.9 mm)
  • Eye Diameter: 15/32" (11.9 mm)
  • Eye Inside Width: 23/32" (18.3 mm)
  • Eye Inside Length: 1 7/16" (36.5 mm)
  • Net Weight: 1.61 lbs (0.73 kg)

Material and Construction:

  • Composition: Drop forged high tensile steel SAE 1035 or 1045
  • Finish: Hot-dipped galvanized for corrosion resistance
  • Safety Factor: Minimum Breaking Load (MBL) is 5 times the Working Load Limit (WLL)
  • Temperature Range: -20°C to +200°C
  • Standard: Manufactured generally to ASTM F1145-92 specifications

Applications:

  • Industries: Construction, marine, offshore, and heavy equipment manufacturing
  • Functions: Load tensioning, cable adjustment, and securing cargo
  • Environments: Outdoor and indoor industrial settings

This Green Pin® Eye Hook Turnbuckle is engineered for both lifting and lashing operations, offering operational flexibility. Its galvanized finish provides protection against environmental factors, contributing to its longevity in Canadian industrial conditions.

For procurement inquiries or to obtain this Green Pin® Eye Hook Turnbuckle for your Canadian operations, select the 'Add to Quote' button to initiate the quoting process.

Size (inches): 1/2” X 6”
Weight (lbs): 0.73

Working Load Limit (t): 1.0
