GREEN PIN LIFTING EYE LENGTH AS DIN580 M18 X 30 (GPAL18DIN)

The Green Pin® Lifting Eye Length as DIN580 M18 X 30 (GPAL18DIN) is a grade 8 lifting component designed for Canadian industrial applications. This alloy steel eye, part number GPAL18DIN, adheres to DIN580 standards and offers a working load limit of 2 t for in-line lifting operations.

Key specifications:

• Thread diameter: M18 X 2.50
• Base diameter: 1 13/32" (35.7 mm)
• Eye outside diameter: 2 15/32" (62.7 mm)
• Eye inside diameter: 1 3/8" (34.9 mm)
• Length: 1 3/16" (30.2 mm)
• Base thickness: 1 7/32" (31 mm)
• Shaft diameter: 9/16" (14.3 mm)
• Net weight: 0.79 lbs (0.36 kg)

This lifting eye operates within a temperature range of -40°C to +200°C, making it suitable for various Canadian industrial environments. The white painted finish provides corrosion resistance for outdoor use.

Industries benefiting from this product include:

• Construction
• Manufacturing
• Shipbuilding
• Mining
• Oil and gas

The Green Pin® Lifting Eye DIN580 M18 X 30 is manufactured from quenched and tempered alloy steel. It features a safety factor where the minimum breaking load equals 5 times the working load limit. The WLL and CE markings are stamped on the body for easy identification.

This lifting eye is part of a range with working load limits from 0.2 t to 36 t, allowing for scalability in rigging systems. For side loading applications, users should note that the working load limit requires reduction.

To obtain pricing information and place an order for the Green Pin® Lifting Eye Length as DIN580 M18 X 30 (GPAL18DIN), click the 'Add to Quote' button on this page.
